2.5mm 4mm 6mm PV1-F Solar Cable For Solar Panel Double Layer Insulated Photovoltaic Cable

Brand Name : F.T

Insulation Material : XLPO

Model Number : PV1-F

Rated Current : 55A

Specification : 6mm ²/ 2.5mm ²/ 4mm ²/ 10mm ²/16mm² /25mm²/35mm ²

Price : usd 0.45 ～ 1/ meter

Working Temperature : - 45 °+120 °

MOQ : 1000

Type : Low Voltage

Payment Terms : L/C,D/A,D/P,Western Union,T/T

Model : PV1-F

Conductor Material : Tin Plated Copper

Packaging Details : Wooden Drum、cardboard box、wooden pallet

Rated Voltage : 1.5kV DC

Certification : tuv

Supply Ability : 800–1500 kilometers per month

Delivery Time : 30 days

Jacket : PVC

Place of Origin : Shaanxi, China

Contact Now

PV1-F Solar Cable 2.5mm 4mm 6mm For Solar Panel Double Layer Insulated Photovoltaic Cable

Conductor Material	tin plated copper
Rated Voltage	1.5kV DC
Rated Current	55A
Model Number	PV1-F
Type	LOW VOLTAGE
Insulation material	Xlpo
Working temperature	- 40 ℃ - 120 ℃
Specification	6mm ²/ 2.5mm ²/ 4mm ²/ 10mm ²/16mm ²/25mm ²/35mm ²

Conductor cross‑section(mm²)	Conductor structure(n/mm)	Stranded outer diameter(mm)	Insul. Thick.(mm)	Conductor resistance(Ω/km)	Ampacity 60℃(A)
2*1.2	30/0.25	0.7	5.00*10.30	13.7	30
2*2.5	49/0.25	0.7	5.20*10.80	8.21	41
2*4.0	56/0.285	0.7	5.50*11.20	5.09	55
2*6.0	84/0.285	0.7	6.20*12.60	3.39	70
2*10.0	84/0.40	0.7	7.5*15.20	1.95	98
2*16.0	128/0.40	0.7	9.60*19.70	1.24	132

Description:

(1) Long-term working temperature of cable conductor -40℃～125℃
(2) The maximum temperature of the cable conductor does not exceed 250℃ during short circuit (the longest duration does not exceed 5s)
(3) It has excellent heat resistance, cold resistance, oil resistance, ultraviolet resistance, ozone resistance, low smoke,
halogen-free, low toxicity and flame retardant.
(4) Thermal shrinkage ≤1%; 20000h thermal life test, elongation at break ≤50%.
(5) The bending radius of the cable should not be less than the following requirements: 4D when D＜8mm, 6D when D≥8mm (Note D is the outer diameter of the cable)
Application Scenarios
XLPO insulated sheathed photovoltaic solar cable ,Usually used for solar panel end DC output or extended connection with solarpanel end output Large photovoltaic power generation Rural building photovoltaic power generation ,City street light photovoltaic power generation.

2.5mm 4mm 6mm PV1-F Solar Cable For Solar Panel Double Layer Insulated Photovoltaic Cable

Product Advantages

Authoritative CertificationsPass TÜV, UL and IEC tests. Tinned copper conductor reduces resistance and power loss for steady power transmission.
Wide Temperature AdaptabilityWorks reliably from ‑40℃ to 120℃, anti‑UV, anti‑ozone and anti‑salt fog, with 25‑year outdoor service life.
Safe & Eco‑friendlyHalogen‑free, low‑smoke and flame‑retardant, suitable for residential, commercial and utility‑scale solar projects.
Flexible & Easy to InstallFine‑stranded structure offers great bendability for rooftop and narrow‑space wiring.
Customizable & Fast DeliverySupport size, printing and packaging customization. Mainstream sizes 4/6/10mm² are in stock for bulk orders.

Product Advantages

Authoritative Certifications

Pass TÜV, UL and IEC tests. Tinned copper conductor reduces resistance and power loss for steady power transmission.

Wide Temperature Adaptability

Works reliably from ‑40℃ to 120℃, anti‑UV, anti‑ozone and anti‑salt fog, with 25‑year outdoor service life.

Safe & Eco‑friendly

Halogen‑free, low‑smoke and flame‑retardant, suitable for residential, commercial and utility‑scale solar projects.

Flexible & Easy to Install

Fine‑stranded structure offers great bendability for rooftop and narrow‑space wiring.

Customizable & Fast Delivery

Support size, printing and packaging customization. Mainstream sizes 4/6/10mm² are in stock for bulk orders.
