GYXTSV-12B1 Fiber Optic Wire 12 Core Single Mode G652D Outdoor Communication

Fiber Count : 12 Core

Delivery Time : 30 days

Price : US $0.18 - 0.35 / Meter

Brand Name : F.T

Structure : Layer-stranded Loose Tube

MOQ : 1000

Color : blue

Certification : CE，VDE,SO 9001

Packaging Details : Wooden Drum、cardboard box、wooden pallet

Fiber Grade : G652D / B1

Fiber Mode : Single Mode

Product Type : Outdoor Fiber Optic Cable

Place of Origin : china

Model Number : Fibre Optic Cable

Supply Ability : 800–1500 kilometers per month

Payment Terms : D/A,L/C,D/P,T/T,Western Union

Contact Now

Fibre Optic Cable GYXTSV-12B1 12-core Single-mode G652D Outdoor Communication

GYXTSV-12B1 is a professional 12-core single-mode outdoor fiber optic cable engineered for long-distance and stable communication transmission. Adopting mature layer-stranded loose tube structure and integrated pressure-resistant design, this optical cable features low signal attenuation, strong tensile resistance and excellent environmental adaptability. Equipped with standard B1/G652D single-mode optical fiber, it ensures ultra-stable data transmission performance and long service life.

Different from ordinary ordinary optical cables with simple structure, GYXTSV-12B1 adds optimized waterproof and pressure-resistant structural design on the basis of traditional communication optical cables. The whole cable is compact in structure, not easy to deform, and effectively resorts external mechanical pressure and moisture erosion. It is widely applicable to outdoor overhead laying, pipeline communication, community network transformation, municipal engineering and other scenarios, being a mainstream reliable wiring solution for medium and long-distance communication projects.

Model & Structural Definition

Each letter and number of GYXTSV-12B1 corresponds to professional structural and performance parameters, meeting international communication industry standards, with clear positioning and strong pertinence in engineering applications:

G: General outdoor communication optical cable, dedicated for public communication network construction
Y: PE outer sheath, with excellent waterproof, anti-aging and weather resistance
X: Optimized loose tube stranded structure, uniform fiber stress, effectively avoiding signal loss caused by extrusion
T: Filled waterproof structure, fully filled with high-quality water-blocking ointment inside the cable core to block moisture penetration
S: Steel tape armored layer, enhances lateral pressure resistance and mechanical protection performance
V: Flame-retardant protective structure, effectively suppresses flame spread and improves construction safety
12: 12-core optical fiber design, meeting medium-capacity network transmission requirements
B1: Standard G652D single-mode optical fiber, the most widely used fiber core for global communication networks

Item	Technical Parameters
Product Model	GYXTSV-12B1
Fiber Core Number	12 Cores
Fiber Type	G652D Single Mode (B1 Standard)
Working Wavelength	1310nm / 1550nm
Transmission Attenuation	≤0.36dB/km (1310nm); ≤0.22dB/km (1550nm)
Operating Temperature	-40℃ ~ +70℃
Tensile Strength	Long-term: ≥1000N; Short-term: ≥1500N
Lateral Pressure Resistance	≥1000N/100mm
Bending Radius	Static: 10×Cable Diameter; Dynamic: 20×Cable Diameter
Outer Sheath Material	High-Density PE Flame-Retardant Material
Waterproof Grade	Full Water-Blocking Structure, Outdoor Waterproof Level
Service Life	25 Years Under Normal Working Conditions
Execution Standard	ITU-T & International Communication Industry Standard

Wide Application Scenarios

With balanced mechanical performance, stable transmission capacity and strong environmental adaptability, GYXTSV-12B1 fiber optic cable is the preferred wiring product for medium and long-distance outdoor communication projects, widely used in the following fields:

Municipal public communication network construction and renovation
Community, campus and park network wiring engineering
Road, bridge and tunnel communication transmission system
Industrial park and remote base station signal transmission
Pipeline buried laying and overhead outdoor communication lines
Enterprise private network and medium-distance data transmission engineering
