Single Core EV Power Cable 2.5mm2 4mm2 Flame Retardant New Energy Vehicle Wire

  • 1
  • 2
  • 3

Packaging Details : Wooden Drum、cardboard box、wooden pallet

Applications : Battery connections for new energy vehicles, motor inverters, and high-voltage wiring for energy storage systems

Outer diameter range (OD) : 3.5 mm – 21.2 mm (increasing with cross-sectional area)

Place of Origin : china

Insulation Material : XLPE

Price : usd 1.2 ～ 16 / meter

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 800–1500 kilometers per month

Certification : CE，VDE,SO 9001

MOQ : 1000

Size : 1*2.5 mm², 1*4.0 mm², 1*10.0 mm², 1*16.0 mm², 1*25.0 mm², 1*35.0 mm², 1*50.0 mm², 1*6.0mm²

Rated voltage : DC 1500 V

Customisation capabilities : Adjust the structure according to customer requirements

Model Number : ev cable

Insulation properties : High insulation resistance

Delivery Time : 7-15 Working Days

Brand Name : F.T

Conductor Material : Oxygen-Free Copper Wire

Rated Voltage : 1000V, 600V

Contact Now

EV Power Cable Single Core 2.5mm² 4mm² Flame Retardant New Energy Vehicle Wire

High-voltage electric vehicle wires and cables are mainly responsible for starting, driving, charging and discharging, air conditioning power, etc. It mainly includes battery systems, power trains, high-voltagea electronic control systems, charging systems, high-voltage equipment, and wiring harness systems. Electric vehicle high-voltage lines are used to connect charging ports and batteries, battery interiors, batteries and engines and other components, as well as battery energy storage equipment and other fields, as a carrier of power transmission.
Main Feature:
1.The product is soft and has a bending radius of less than 5D;

2. High and low temperature resistance, oil resistance, acid and alkali resistance, water resistance, wear resistance, cracking resistance, UV resistance;

3. Good flame retardant performance; Good conductivity, small conductor temperature rise;
4. All materials comply with RoHS 2.0 environmental standards.

Cable specifications

Models Structure OD Jacket Conductor Voltage
2.5mm² 80/0.20mm 3.5mm XLPE Oxygen-Free Copper 1500V
4mm² 132/0.20mm 4.5mm XLPE Oxygen-Free Copper 1500V
6mm² 196/0.20mm 5.0mm XLPE Oxygen-Free Copper 1500V
10mm² 336/0.20mm 6.4mm XLPE Oxygen-Free Copper 1500V
16mm² 532/0.20mm 8.0mm XLPE Oxygen-Free Copper 1500V
25mm² 798/0.20mm 10.2mm XLPE Oxygen-Free Copper 1500V
35mm² 1121/0.20mm 11.5mm XLPE Oxygen-Free Copper 1500V
50mm² 1596/0.20mm 13.2mm XLPE Oxygen-Free Copper 1500V
70mm² 2231/0.20mm 15mm XLPE Oxygen-Free Copper 1500V
95mm² 3182/0.195mm 17.3mm XLPE Oxygen-Free Copper 1500V
120mm² 4033/0.195mm 19.5mm XLPE Oxygen-Free Copper 1500V
150mm² 5022/0.195mm 21.2mm XLPE Oxygen-Free Copper 1500V

EV Power cable application

  • Connection between power batteries and motor controllers in new energy vehicles
  • Internal wiring of on-board high-voltage power distribution units (PDUs) and charger
  • DC connection between battery clusters and PCS in residential/commercial and industrial energy storage systems
  • High-voltage power supply for special-purpose vehicles such as electric forklifts and construction machinery
  • Internal module connections in 1500V DC charging stations

Single Core EV Power Cable 2.5mm2 4mm2 Flame Retardant New Energy Vehicle Wire

FAQ

Q1:What is the rated voltage of this cable?
A:Rated for DC 1500V, suitable for high-voltage EV and energy storage systems.
Q2:What material is the conductor made of?
A:Made of oxygen-free copper with multi-strand design, offering high conductivity and flexibility.
Q3:What are the available cross-section sizes?
A:Available from 2.5mm² up to 150mm² (see the full spec table for detailed options).
Q4:Is the cable customizable?
A:Yes, we can customize the structure, OD, insulation material and length to meet your specific requirements.
Q5:What applications is this cable suitable for?
A:Ideal for EV battery connections, motor controllers, PDU, energy storage systems, and 1500V DC charging stations.
Q6:What is the insulation material?
A:XLPE (cross-linked polyethylene), which provides high voltage resistance, heat resistance, and good aging performance.
